The Phantom Aura 760XP is a powerful 7×60W RGBW LED moving head designed and manufactured in-house by Wincode Optronics. It combines three premium visual effects inspired by top brands in one compact fixture:
Perfect for concerts, theaters, clubs, festivals, TV studios, and rental productions.
| Quantity: | |
|---|---|
WOP-LM760XP
Wincode Optronics
Phantom Aura 760XP – 7×60W RGBW LED Moving Head
The Phantom Aura 760XP is a high-performance 7×60W RGBW LED moving head engineered by Wincode Optronics for professional stage, concert, theater, club, festival, and rental applications.
This innovative fixture combines three premium visual effects in a single compact design:
Aura Backlight – stunning halo/glow effect inspired by Martin Aura 760XP
Bee Eye Lens Rotation – dynamic beam and lens movement reminiscent of Clay Paky
Edge Glow & Auxiliary Lighting – elegant edge illumination and rich auxiliary effects similar to Ayrton Edge series
With full in-house design control (optics, electronics, software, structure, and appearance), the Phantom Aura 760XP delivers superior brightness, smooth color mixing, and versatile performance.
Key Features at a Glance
Total power: 560W
Light source: 7 × 60W high-brightness RGBW LEDs
Magic Eye: 12 × 10 × 0.2W + 12 × 0.2W
Auxiliary light: 210 × 0.2W
Exclusive single-piece designer optical system
Beam angle: 3.4°–39° | Spot angle: 6°–54°
Full 360° panoramic rendering + linear CTO stepless color temperature
16-bit XY movement (X: 540°, Y: 270°)
Channel modes: 20 / 28 / 40 / 114CH
Control: DMX512, RDM, master-slave, auto-run, sound-active
Dimming: 0–100% linear, flicker-free
Operating temperature: 0°C to 45°C
IP rating: IP20
Housing: durable metallic black finish
Dimensions: 396.5 × 275 × 507.5 mm (15.6" × 10.83" × 19.9")
Weight: 14.7 kg (32.41 lbs)
Illuminance Performance
Narrow beam (3.4°) @ 5 m: 51,400 Lux
Wide wash (54°) @ 5 m: 965 Lux Excellent far-throw capability and uniform wash coverage.
Ideal ApplicationsConcerts • Touring productions • Theaters • TV studios • Nightclubs • Festivals • Weddings • Corporate events • Rental fleets
Why Choose Phantom Aura 760XP?Proven multi-effect fusion + high-brightness output + compact design + full customization flexibility = the smart choice for professional lighting designers and rental companies seeking premium performance without premium pricing.
Contact us for quotes, custom versions, upgrades (12×LED / 7×150W options), samples, or bulk pricing!
