Tetra Bar 12×60W/40W LED Pixel Moving Zoom Bar

1. Equipped with 12×40W/60W RGBW 4 in 1 LEDs
2. 65mm Square Lens (bigger than public mold body)
3. Pure color, good consistency, high brightness
3.Zoom range: 3 ° to 40 °
4.Extended functions: support RDM, wireless signals is available
5.Tilt movement range: 220°
  • WOP-LE1240Z
  • Wincode Optronics

WOP-LE1240Z is powered with 12 pieces 60W/40W RGBW 4 in 1 LEDs, a linear light effect led product, with 3 ° to 40 ° focusing range, forming a "blade" mirror effect cutting space at 3 ° and a wide dyeing range at 40 ° and pure color without color difference; single point control of lamp beads can form rich effects, and the distance between two lamp beads is the same without dark area, so as to seamlessly.It’s one impressive dynamic LED Zoom Pixel Moving Bar Light with beam effects, pixel effects, wash effects for night club, DJ Events…

Product parameters

Light Source

Light Source: 12x60W/40W RGBW LED

LED life expectancy: 30,000 hours

Optical System & Effects

Zoom range: 3°—40°

RGBW color mixing

Outstanding color mixing effect with variable speed

High resolution dimmer 0–100%

Electromechanical Effects

Linear motorized zoom

Tilt movement range: 220°

Control & Program

5 High-end ergonomics buttons

Display: TF display

Protocols: DMX512, RDM

DMX Protocol modes: 2

Control channels: 16/56 CH

Firmware upgrade via DMX link

Electrical & Connectors

Power supply with electronic auto-ranging

Input voltage range: AC 100-240V, 50/60Hz

Power consumption: 560W/660W

Power in/out: Power Connector in/out

Data in/out: 3-pin & 5-pin XLR

Fixture Specification

Height: 120mm

Width: 282mm

Depth: 1080mm

Weight: 25kg

Work environment

Maximum ambient temperature: 40°C

Maximum surface temperature: 65°C

Minimum operating temperature: 0°C


CE compliant


Horizontal or vertical mounting

Operating position is universal

2x fast-lock clamps for 50mm truss

Safety cable attachment point

Included items

User Manual

Power Cable

Carry handles (minimum load 60kg)

Safety rope device

2x fast-lock clamps for 50mm truss


Entertainment: night clubs, live house, Events, DJ, Disco, club, KTV& other entertainment centers …
