Tetra Bar 12×60W LED Pixel Moving Zoom Bar with Motorized Tilt

1. Equipped with 12×40W/60W RGBW 4 in 1 LEDs
2. 65mm Square Lens (bigger than public mold body)
3. Pure color, good consistency, high brightness
3.Zoom range: 3 ° to 40 °
4. Extended functions: support RDM, wireless DMX512, Artnet is available
5.Tilt movement range: 220°
Availability:
Quantity:
  • WOP-LE1240Z

  • Wincode Optronics

WOP-LE1240Z 12×60W/40W Motorized Tilt LED Moving Pixel  Zoom Bar is a super powerful LED based moving head linear light of stage lights, very similar as Robe Tetra2, GLP Impression X4 Bar, EK DIAMONDBACK, Clay Paky Volero Batten Aqua.  Compact and stylish design, fast and quiet TILT movement; it features 12 pieces high power 60W or 40W RGBW 4 in 1 LEDs, pixel mapping control with 3 ° to 40 ° overall zoom range, sharpy beam forming a "blade" mirror effect cutting space at 3 ° and a wide dyeing range at 40 ° and pure color without chromatic aberration; Oversized quad glass optics bring you a brighter, bigger, sharper beam effect and a wider range wash effect. Built-in rich auto running effects, outstanding dimming solution comparable to Martin Lighting, even at low brightness it's flicker-free during dimming. When multiple lights are seamlessly spliced, the light beams emitted by equidistantly arranged lamp beads can cover a wide area. It’s one impressive dynamic LED Zoom Pixel Moving Bar Light with beam effects, pixel effects, wash effects, which greatly meets the lighting needs of concerts, variety shows and other places.


The fixture is tuned with proper LED refresh rate for flicker free operation for TV and FILM. It’s a perfect option for large scale live concerts, TV productions, road shows, clubs/bars, weddings, etc.


Features

  • Light Source: 12x40W/60W RGBW LED

  • Zoom range: 3-40°

  • Effects:Built-in rich auto running effects, outstanding dimming solution comparable to Martin Lighting, even at low brightness it's flicker-free during dimming

  • Oversized quad glass optics bring you a brighter, bigger, sharper beam effect and a wider range wash effect, pixel mapping, RDM support (Artnet, Wireless DMX512 custom)

  • Connected quantity:

    • Maximum QTY of DMX connecting mode: 32 sets

    • Maximum QTY of Power supply connecting mode:120V - 4 sets / 230V - 7 sets




led zoom pixel bar12×40W Pixel Zoom Moving Bar LightMotorized Tilt led pixel zoom bar Motorized Tilt led pixel zoom bar led pixel batten zoom bar lightTetra Zoom Bar



Product parameters

Light Source

Light Source: 12x60W/40W RGBW LED

LED life expectancy: 30,000 hours



Optical System & Effects

Zoom range: 3°—40°

RGBW color mixing

Outstanding color mixing effect with variable speed

High resolution dimmer 0–100%



Electromechanical Effects

Linear motorized zoom

Tilt movement range: 220°



Control & Program

5 High-end ergonomics buttons

Display: TF display

Protocols: DMX512, RDM

DMX Protocol modes: 2

Control channels: 16/56 CH

Firmware upgrade via DMX link



Electrical & Connectors

Power supply with electronic auto-ranging

Input voltage range: AC 100-240V, 50/60Hz

Power consumption: 560W/660W

Power in/out: Power Connector in/out

Data in/out: 3-pin & 5-pin XLR








Fixture Specification

Height: 120mm

Width: 282mm

Depth: 1080mm

Weight: 25kg



Work environment

Maximum ambient temperature: 40°C

Maximum surface temperature: 65°C

Minimum operating temperature: 0°C



Approvals

CE compliant



Installation

Horizontal or vertical mounting

Operating position is universal

2x fast-lock clamps for 50mm truss

Safety cable attachment point



Included items

User Manual

Power Cable

Carry handles (minimum load 60kg)

Safety rope device

2x fast-lock clamps for 50mm truss


Applications:

Entertainment: night clubs, live house, Events, DJ, Disco, club, KTV& other entertainment centers …
