480W LED BSWF Hybrid Moving Head Light

1.High power 480W LED Engine
2.Beam Spot Wash Framing 4 in 1
3.Linear CMY+CTO
4.RDM Support
  • WOP-LM1017

  • Wincode Optronics

The WOP-LM1017 is a new generation professional and intelligent Hybrid LED moving head Light, Beam spot, wash, framing designed with a full CMY color mixing system plus CTO color correction, smooth and linear zoom from 7°-42°. The light features a new high intensity and efficiency cool white 480W LED engine (8500K) delivering ultra high light output through a set of high resolution and precise optics that helps to provide extremely clear and even spot coverage. It offers a full complement of other professional characteristics, a rotating gobo wheel with 7 rotating and interchangeable glass gobos, a static gobo wheel with 12 gobos, a color wheel with 8 dichroic colors, 2 rotating prisms, frost filter, linear electronic focus, linear dimmer, variable speed shutter/strobe, full color 180° reversible TFT display with 5 control buttons, etc. And supports DMX, RDM (Remote Device Management).

Source: 480W white LED engine

Life: >20,000H
Standard mode Ra>70

High CRI mode Ra>90

AC100-240V 50/60Hz

Switch power supply

Input power: 550w


Pan movement: 540°/630° optional (16 bit)
Tilt movement: 270° (16 bit )
Advanced motion system: auto repositioning, fast, quiet and smooth


CMY infinite color mixing

CTO linear

7 dichroic filters + open, bidirectional color rainbow can be created,

even and smooth CMY+CTO color change system

1 Rotating gobo wheels:
7 interchangeable + open ,with shaking effect and gobo wheel can be positioned

1 fixed gobo wheel:

8 interchangeable+open,with gobo shaking effect


DMX channels:34/54 CH

prism:1 bidirectional 5-facet rotating prism , prism can be positioned
Focus: linear focus

5%-100% electronic Iris
Shutter: electronic, variable from 1-25Hz or random
Dimming: 0-100% linear dimming
Frost: heavy frost
Zoom: 4.5°- 55°linear zoom

Patented framing system: 1 set of all directional framing systemwith 8 framing blade precise position can be cutting 90° rotation,full field travelwith the ability to create differentshapes.
Animation wheel: special dynamic flame or water effect

Flicker free management

With quiet mode and High-power mode

15 second standby auto lock
Pan/ Tilt disengage (hold MENU and ENTER button)

Run time of LED engine and fixture

Optional ArtNET control
RDM compatible

intelligent fan noise control,intelligent energy-saving


body size :370 X283 X713mm

Packing Dimension in fly case 2in1: 83X37X45 MM

Net Weight: 29 KG

Gross Weight(2 pcs in a fly case ): 108KG
